FORDIA Plate Underpacking Film
Engineered for dimensional stability in long-run commercial printing. Our self-adhesive polyester film provides precise gauge control and superior chemical resistance.
Engineered for High-Precision Printing
Advanced polymer construction delivers unmatched stability and protection for modern offset presses.
Self-Adhesive Design
Strong initial tack ensures secure placement, while specialized adhesive allows for clean removal without leaving residue on cylinders.
Anticorrosion Protection
Formulated with active anti-corrosion inhibitors to actively protect valuable press roller surfaces from oxidation and wear.
Chemical Resistance
Exceptional resistance to aggressive printing solvents, automated blanket washes, and typical pressroom cleaning agents.
Long Service Life
High-density polyester core maintains precise caliper under sustained pressure, reducing the need for frequent replacement.
Technical Specifications
| Base Material | High-Density Polyester (PET) |
|---|---|
| Adhesion Strength | > 15 N/25mm (Standard Peel Test) |
| Available Gauges | Customizable Sheet Size Thickness:0.08 – 0.10 – 0.12 – 0.14 – 0.16 – 0.18 – 0.20 – 0.22 – 0.24 – 0.26 – 0.28 – 0.30 – 0.32 – 0.35 – 0.40 – 0.45 – 0.50-0.55 mm |
| Standard Roll Widths | 1050mm, 1300mm (Custom widths available), 30m per rolll |
| Temperature Tolerance | Up to 150°C (Short term) |
Optimized for Industrial Print Environments
-
print
High-Speed Offset Presses
Maintains structural integrity under the extreme rotational speeds and pressures of modern offset equipment.
-
auto_stories
Long-Run Commercial Printing
Dimensional stability prevents gauge loss over millions of impressions, ensuring consistent print quality.
-
view_agenda
Plate Underlay
Provides the precise foundational height required for optimal ink transfer and dot reproduction.
Request Technical Documentation
Connect with our engineering team to discuss gauge requirements, custom roll widths, or to request a sample for pressroom evaluation.
